Workflow XML Parser Tool

Résumé

Use the Workflow XML Parser tool to extract workflow properties, tool configurations, and connection details.

Marketplace Tool

This tool is not automatically installed with Alteryx Designer. To use this tool, download it from the Alteryx Marketplace.

Requirements and Compatibility Notes

The Workflow XML Parser tool is compatible with Designer and Server version 2022.1 and newer.
The tool is compatible with both Alteryx Multi-threaded Processing (AMP) and the original Engine.

Tool Components

The Workflow XML Parser tool has 4 anchors:

Input anchor: I input anchor: This anchor serves as the tool's input and should contain the target workflow XML in a single record.
Output anchors:
- W (Workflows) output anchor: This anchor outputs your workflow properties. This includes all elements from the Properties and MetaInfo sections of the Workflow XML. Events, Constants, and RuntimeProperties are output as XML objects since many child elements can exist for each parent element.
- T (Tools) output anchor: This anchor outputs your tool properties. The most common tool configuration elements are parsed and the full tool XML is provided for further analysis. Refer to the section below for details on what elements are parsed.
- C (Connections) output anchor: This anchor outputs all connection details, including all origin and destinations along with the anchor names.

Configure the Tool

This tool requires the entire workflow XML to reside in a single cell (single column and single row) of your input data. To best achieve this, open files using the Blob Input tool to pull the yx* binaries into the workflows. Then, convert the workflow binaries to a string using the Blob Convert tool set to UTF-8.

Choose field that contains Workflow XML: Select the field (column) that contains the workflow XML string.

Workflow Output Fields

Field Name	Description	Menu Location	Menu Item	Corresponding Option	Values	Notes
`Workflow_yxmdVer`	The version of Alteryx Designer that was used to modify the workflow last.	Auto Created*		Built-in	YYYY.X
`Workflow_RunE2`	Is the AMP engine enabled for the workflow?	Runtime		Use AMP Engine	T or Null
`Property_XML`	Full XML for the "Properties" section.	N/A		N/A	N/A
`Properties_Memory_max`	Specific Memory Amount defined by the user (in MBs).	Runtime		Memory Limit (MB)	Integer
`Properties_Memory_default`	True: Use Global Default, False: Use Specific Amount.	Runtime		Memory Limit Radio	True or False
`Properties_GlobalRecordLimit`	The user-defined limit for all inputs (blank = no limit).	Runtime		Record Limit for All Inputs	Integer
`Properties_TempFiles`	A specific temp folder defined by the user.	Runtime		Use Specific Folder	Folder Path
`Properties_TempFiles_default`	True: Use Global Default, False: Use Specific Folder.	Runtime		Temporary Files Radion	True or False
`Properties_Annotation_on`	The Annotations visibility setting.	Canvas		Annotations	True or False
`Properties_Annotation_includeToolName`	Are Annotations displayed with the tool name?	Canvas		Annotations	True or False
`Properties_ConvErrorLimit`	Number of conversions to limit (0 = no limit).	Runtime		Maximum Errors per Location	Integer
`Properties_ConvErrorLimit_Stop`	Stop processing when the limit is reached.	Runtime		Checkbox	True or False
`Properties_CancelOnError`	Cancel running the workflow on error.	Runtime		Checkbox	True or False
`Properties_DisableBrowse`	Disable all Browse tools.	Runtime		Checkbox	True or False
`Properties_EnablePerformanceProfiling`	Enable Performance Profiling.	Runtime		Checkbox	True or False
`Properties_RunWithE2`	Use AMP engine.	Runtime		Checkbox	True or False
`Properties_SortedGrouping`	Engine Compatibility Mode.	Runtime		Checkbox	True or Null
`Properties_PredictiveToolsCodePage`	The code page to use for Predictive tools in the workflow. This setting overrides the selection in Language and Region User Settings.	Runtime		Dropdown	Code page values.
`Properties_DisableAllOutput`	Disable all tools that write output.	Runtime		Checkbox	True or False
`Properties_ShowAllMacroMessages`	Show all macro messages.	Runtime		Checkbox	True or False
`Properties_ShowConnectionStatusIsOn`	Determine what level of Connection Progress is shown (False = hide).	Canvas	Connection Progress	Dropdown	True or False
`Properties_ShowConnectionStatusOnlyWhenRunning`	Determine if connection progress is shown only while running. False = Show, True = Show only when running.	Canvas	Connection Progress	Dropdown	True or False
`Properties_ZoomLevel`	The zoom value when opening the workflow.	Built-In		Built-In	Integer
`Properties_LayoutType`	The direction of the tool layout in the canvas.	Canvas	Layout Direction	Dropdown	Horizontal or Vertical
`Properties_IsTemplate`	Defines if the workflow is a template (YXTD).	Built-In		Built-In	True or False
`MetaInfo_NameIsFileName`		Meta Info	Use File Name	Radio Button	True or False
`MetaInfo_Name`		Meta Info	Custom	Radio, Text Input	Text
`MetaInfo_Description`	The description of the workflow shown either in Server, on the App splash screen, or on hover in the Designer tool palette.	Meta Info	Description	Text Input	Text
`MetaInfo_RootToolName`	The root tool name that helps identify versions to group.	Meta Info	Root Tool Name	Text Input	Text	Macros Only
`MetaInfo_ToolVersion`	The version of the tool to use when multiple macros exist with the same RootToolName.	Meta Info	Tool Version	Text Input	Text	Macros Only
`MetaInfo_ToolInDb`	Identifies if the macro is an In-Database tool.	Meta Info	Tool In-Database?	Checkbox	True or False	Macros Only
`MetaInfo_CategoryName`	The category where the macro can be found in the Designer tool palette.	Meta Info	Category Name	Text Input	Text	Macros Only
`MetaInfo_SearchTags`	The keywords used to find the tool when searching.	Meta Info	Search Tags	Text Input	Text	Macros Only
`MetaInfo_Author`	The name of the workflow author.	Meta Info	Name	Text Input	Text
`MetaInfo_Company`	The company of the workflow author.	Meta Info	Company	Text Input	Text
`MetaInfo_Copyright`	The copyright information for the workflow.	Meta Info	Copyright	Text Input	Text
`MetaInfo_DescriptionLink_actual`	The description link (used in the interface for apps and in the tool palette for macros).	Meta Info	URL	Text Input	Text
`MetaInfo_DescriptionLink_displayed`	The description link display text (used in the interface for apps and in the tool palette for macros).	Meta Info	Display Text (optional)	Text Input	Text
`MetaInfo_WorkflowId`	The current workflow ID of the file.	Built-In
`MetaInfo_Telemetry_PreviousWorkflowId`	The previous workflow ID of the file.	Built-In
`MetaInfo_Telemetry_OriginWorkflowId`	The initial workflow ID of the file.	Built-In
`MetaInfo_PlatformWorkflowId`	The corresponding platform workflow ID.	Built-In
`MetaInfo_Example_Description`	The hyperlink text to display (for example, "Open Example").	Manual XML Entry
`MetaInfo_Example_File`	The file path for One Tool Example workflow.	Manual XML Entry				The example file path needs to be present in the `Samples\Learn` one tool at a time folder.
`Events_OuterXML`	The full XML object for all Events.
`Constants_OuterXML`	The full XML object for all Constants.
`RuntimeProperties_OuterXML`	The full XML object for all Runtime Properties.
`MetaInfo_OuterXML`	The full XML object for all MetaInfo for the workflow.

Tool Output Fields

Avertissement

Tools can have multiple rows if there are 2 or more of the elements parsed. This is common in the Formula tool along with tools that have multiple file connections.

Note

Rows with ParentIds and null ToolIds are empty tool containers.

Field Name	Description	Relevant Tools
`ToolID`	The ToolID of the node.	All
`Origin_Tools`	The ToolIDs of upstream tools. Data originates from these tools and flows into the specified tool.	Any tool that is connected to an upstream tool.
`Destination_Tools`	The ToolIDs of downstream tools. Data originates from the specified tool and flows into these tools.	Any tool that connects downstream to another tool.
`ParentToolId`	The Tool Container or Control Container ToolID in which the specified tool is located.	Only filled in when the tool is in a container.
`EngineSettings_EngineDll`	The tool-specific EngineDll.
`EngineSettings_EngineDllEntryPoint`	The tool-specific EngineDllEntryPoint.
`EngineSettings_Macro`	The tool-specific macro path (only applicable for macros).
`GuiSettings_Plugin`	The tool-specific Gui Plugin.
`GuiSettings_Position_x`	The tool canvas horizontal location.
`GuiSettings_Position_y`	The tool canvas vertical location.
`GuiSettings_Position_width`	The tool width.
`GuiSettings_Position_height`	The tool height.
`Properties_OuterXML`	The full XML element for the tool properties.
`Properties_Configuration_joinByRecordPos`	True and False settings for whether the Join tool is set to "Join by Record Position."	Join, Join Multiple
`Annotation_OuterXML`	The full XML for annotations.
`Properties_Annotation_DisplayMode`	The display mode of tool annotation (Canvas Settings, Always, Never).
`Properties_SdkSettings_Manifest`	True or False for Manifest.	SDK Tools
`Properties_SdkSettings_Language`	The SDK language used.	SDK Tools
`Properties_SdkSettings_PluginDir`	The stored directory for the SDK tool.	SDK Tools
`Properties_SdkSettings_Transport`	The language-specific transport layer.	SDK Tools
`Properties_SdkSettings_OuterXML`	The full XML for tool SDK settings.	SDK Tools
`Configuration_OuterXML`	The tool XML (accessible in tool configuration).
`Dependencies_OuterXML`	The full XML for tool-specific dependencies.
`MetaInfo_OuterXML`
`Formula_Field`	Formula Field Name	Formula Tool
`Formula_Size`	Formula Field Size	Formula Tool
`Formula_Type`	Formula Field Type	Formula Tool
`Formula_Enabled`	Describes if the formula expression is enabled.	Formula Tool
`Expression`	Formula Expression	Dynamic Select, Filter, Formula, Multi-Field Formula, Multi-Row Formula

Field Name	Description	Relevant Tools
`Filter_Simple`	Formula Expression	Filter Tool
`Filter_Field`	Simple filter field selected.	Filter Tool
`Filter_Operator`	Simple filter field operator.	Filter Tool
`Filter_Operands`	Simple filter operands.	Filter Tool
`DefaultAnnotationText`	The default annotation text of a tool.	Any
`AnnotationText`	The custom annotation text of a tool.
`Python_JupyterProduction`	True or False setting to determine if Jupyter is set to run in production mode.	Python Tool
`Python_vEnvName`	The Python environment used for running the script.	Python Tool
`Python_vEnvName_OuterXML`	The full XML for the vEnvName element.	Python Tool
`Python_Notebook`	The script run while the Python tool is in interactive mode.	Python Tool
`Python_productionModeScript`	The script run while the Python tool is in production mode.	Python Tool
`RScript`	The script run in the R tool.	R Tool
`File_File`	The full file path entered in the text box.	Dynamic Input, Input Data, Macro Input, Output Data, Run Command
`File_OutputFileName`	Determines if the file name is output as a full path or only the file name.
`File_FileFormat`	The numeric value for the file format.	Dynamic Input, Input Data, Macro Input, Output Data, Run Command
`File_SearchSubDirs`	The option checked to Search Sub Directories for a file.
`File_RecordLimit`	The record limit for file input.
`File_OuterXML`	The full XML for the file element.	Dynamic Input, Input Data, Macro Input, Output Data, Run Command
`File_MaxRecords`	The record limit for file output.	Dynamic Input, Input Data, Macro Input, Output Data, Run Command
`File_Table`	The table referenced as a part of the file input.	Dynamic Input, Input Data, Macro Input, Output Data, Run Command
`File_CreateMode`	In-DB Create Mode	In-DB
`CreateMode_OuterXML`	The full XML for In-DB Create Mode.
`File_PreSQL`	The PreSQL statement run prior to executing a query.	Dynamic Input, Input Data, Macro Input, Output Data, Run Command
`File_PostSQL`	The PostSQL statement run after executing a query.	Dynamic Input, Input Data, Macro Input, Output Data, Run Command
`RScript_OuterXML`	The full XML for the R script element.
`FileFormatName`	The readable format name for file format referenced in `File_FileFormat`.
`DesignerToolName`	The tool name as seen in Designer.
`DesignerToolCategory`	The tool category as seen in Designer.
`ToolGroup`

Connection Output Fields

Field Name	Description
`Origin_ToolID`	The tool ID at the beginning of the connection.
`Origin_Connection`	The anchor name at the beginning of the connection.
`Destination_ToolID`	The tool ID at the end of the connection.
`Destination_Connection`	The anchor name at the end of the connection.
`name`	Connection Name
`Wireless`	Is the connection wireless (True or False)?
